Main purpose

The ML-3C soil seedless density meter can measure the wet density, moisture content, dry density, and compaction degree of soil in roads and foundations. Used for measuring the wet density and moisture content of compacted materials within the following ranges: excavation and backfilling construction; Underground passages, basements, and foundations; Backfilling, ditches, and garbage; Roadbed foundation and trench backfilling. Mainly suitable for clay and non cohesive soil, it can also be used for lime or cement modified soil, gravel soil and other soils.

Standards:ASTM D6938, ASTM D7830, ASTM D7698

Main Features

v The user interface is simple and easy to learn, convenient to use, with both Chinese and English interfaces, suitable for each member of the group to use.

v Fast, lightweight, and highly repeatable real-time readings.

v Point to point RF technology.

v Display measurement results within 2-3 minutes.

v Using digital DDS frequency synthesis technology, no calibration is required, and there will be no data drift during use.

Technical indicators

v Wet density range: according to the measurement range of compacted soil in the test standards

v Wet density accuracy: 0-2% of standard test

v Moisture content accuracy: 0-3% of standard test

v 5-inch high brightness touch screen, clearly visible under strong light

v Detection depth: Depth measurement of 300mm

v The internal data logger can store 50000 readings (supporting up to 32GTF card storage)

v Equipped with a USB interface, the USB flash drive can directly transfer data or perform internal software upgrades

v Power supply: 12V, 2600mAh rechargeable battery, continuous operation for 20 hours

v Operating temperature: ambient temperature -5 ℃ to 45 ℃

v Volume and weight: Host volume: 206mm * 120mm * 50mm)

v Weight: 0.96kg

v Work environment requirements:

Environmental temperature: 0 ℃~45 ℃

Relative humidity:<90% RH
